# PORT

config ports 1 speed auto flow_control disable state enable description "C_IPA_528116_35"
config ports 1-28 learning enable
config ports 1-28 mdix auto
config ports 2 speed auto flow_control disable state enable description "C_IPA_40067_36"
config ports 3 speed auto flow_control disable state enable description "C_IPA_4879_56"
config ports 4 speed auto flow_control disable state enable description "C_IPA_04231_23"
config ports 5 speed auto flow_control disable state enable description "C_IPA_online_82_58"
config ports 6 speed auto flow_control disable state enable description "C_IPA_5070_65"
config ports 7 speed auto flow_control disable state enable description "C_IPA_05202_101"
config ports 8 speed auto flow_control disable state enable description "C_IPA_5256_107"
config ports 9 speed auto flow_control disable state enable description "C_IPA_8465_75"
config ports 10,24 speed auto flow_control disable state enable description "VACANT"
config ports 11 speed auto flow_control disable state enable description "C_IPA_9566_33"
config ports 12-23 speed auto flow_control disable state disable description "VACANT"
config ports 25 medium_type fiber speed auto flow_control disable state enable description "N_ORB.001.TERESH.257.SD6.A05"
config ports 25-26 medium_type fiber learning enable
config ports 25 speed auto flow_control disable state enable description "N_ORB"
config ports 26 medium_type fiber speed auto flow_control disable state enable description "N_ORB.001.NOYAB.39.SA1.A26"
config ports 26-28 speed auto flow_control disable state disable clear_description

# VLAN

disable asymmetric_vlan
disable qinq
config vlan default delete 1-28
config vlan default advertisement enable
create vlan PPPoE tag 3
config vlan PPPoE add tagged 25-28
config vlan PPPoE add untagged 1-23
create vlan ERPS_vlan tag 72
config vlan ERPS_vlan add tagged 25-28
create vlan VLAN100 tag 100
config vlan VLAN100 add tagged 25-26
create vlan VLAN256 tag 256
config vlan VLAN256 add tagged 25-28
create vlan TV_mgmt2 tag 785
config vlan TV_mgmt2 add tagged 25-26
config vlan TV_mgmt2 add untagged 24
disable gvrp
config gvrp 1-23 state disable ingress_checking disable acceptable_frame admit_all pvid 3
config gvrp 24 state disable ingress_checking disable acceptable_frame admit_all pvid 785
config gvrp 25-28 state disable ingress_checking disable acceptable_frame admit_all pvid 1

# MULTI FILTER

create mcast_filter_profile profile_id 1 profile_name IPTV-Multicast-GroupChanell
config mcast_filter_profile profile_id 1 add 226.100.10.1-226.100.10.81
config mcast_filter_profile profile_id 1 add 239.1.29.1-239.2.29.10
config mcast_filter_profile profile_id 1 add 233.12.144.1-233.12.144.90
config control_pkt ipv4 igmp replace priority none dscp none
config control_pkt ipv4 vrrp replace priority none dscp none
config control_pkt ipv4 rip replace priority none dscp none
config control_pkt ipv4 pim replace priority none dscp none
config control_pkt ipv4 dvmrp replace priority none dscp none
config control_pkt ipv4 ospf replace priority none dscp none
config control_pkt ipv6 mld replace priority none dscp none
config control_pkt ipv6 nd replace priority none dscp none
config max_mcast_group port 1-24 max_group 2
config max_mcast_group port 25-28 max_group 256
config limited_multicast_addr ports 1-24 add profile_id 1
config limited_multicast_addr ports 25-28 delete profile_id 1

# SNOOP

enable igmp_snooping
config igmp_snooping data_driven_learning max_learned_entry 56
enable igmp_snooping multicast_vlan
config igmp_snooping vlan_name default host_timeout 260 router_timeout 260 leave_timer 2 state disable fast_leave disable
config igmp_snooping data_driven_learning vlan_name default aged_out disable
config igmp_snooping data_driven_learning vlan_name default state disable
config igmp_snooping querier all query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable
config igmp_snooping vlan_name PPPoE host_timeout 260 router_timeout 260 leave_timer 2 state disable fast_leave disable
config igmp_snooping data_driven_learning vlan_name PPPoE aged_out disable
config igmp_snooping data_driven_learning vlan_name PPPoE state enable
config igmp_snooping vlan_name ERPS_vlan host_timeout 260 router_timeout 260 leave_timer 2 state disable fast_leave disable
config igmp_snooping data_driven_learning vlan_name ERPS_vlan aged_out disable
config igmp_snooping data_driven_learning vlan_name ERPS_vlan state enable
config igmp_snooping vlan_name VLAN100 host_timeout 260 router_timeout 260 leave_timer 2 state disable fast_leave disable
config igmp_snooping data_driven_learning vlan_name VLAN100 aged_out disable
config igmp_snooping data_driven_learning vlan_name VLAN100 state enable
config igmp_snooping vlan_name VLAN256 host_timeout 260 router_timeout 260 leave_timer 2 state disable fast_leave disable
config igmp_snooping data_driven_learning vlan_name VLAN256 aged_out disable
config igmp_snooping data_driven_learning vlan_name VLAN256 state enable
config igmp_snooping vlan_name TV_mgmt2 host_timeout 260 router_timeout 260 leave_timer 2 state disable fast_leave disable
config igmp_snooping data_driven_learning vlan_name TV_mgmt2 aged_out disable
config igmp_snooping data_driven_learning vlan_name TV_mgmt2 state enable
config igmp access_authentication port 1-28 state disable
config cpu_filter l3_control_pkt 1-24 rip ospf vrrp pim dvmrp igmp_query state enable
config cpu_filter l3_control_pkt 25-28 all state disable

# ERPS

config erps log enable
create erps raps_vlan 72
config erps raps_vlan 72 timer holdoff_time 0 guard_time 500 wtr_time 1
config erps raps_vlan 72 rpl_port none
config erps raps_vlan 72 rpl_owner disable
config erps raps_vlan 72 ring_mel 1
config erps raps_vlan 72 ring_port west 26
config erps raps_vlan 72 ring_port east 25
config erps raps_vlan 72 protected_vlan add vlanid 3
config erps raps_vlan 72 protected_vlan add vlanid 5
config erps raps_vlan 72 protected_vlan add vlanid 100
config erps raps_vlan 72 protected_vlan add vlanid 256
config erps raps_vlan 72 protected_vlan add vlanid 785
enable erps

# PORT

enable jumbo_frame
config autocable_diag ports 1-28 state disable
config ports 1-28 linkchange_logs enable
config ports 1,3,24 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto
config ports 2 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 4 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 5 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 6 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 7 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 8 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 9 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 10 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 11-23 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state disable mdix auto
config ports 25-26 medium_type copper speed auto capability_advertised 10_half 10_full 100_half 100_full 1000_full flow_control disable learning enable state enable mdix auto
config ports 25-26 medium_type fiber speed auto capability_advertised 1000_full flow_control disable learning enable state enable
config ports 27-28 speed auto capability_advertised 1000_full flow_control disable learning enable state enable

# IGMP_MULTICAST_VLAN

enable igmp_snooping multicast_vlan
config igmp_snooping multicast_vlan forward_unmatched disable
create igmp_snooping multicast_vlan IPTV 5
config igmp_snooping multicast_vlan IPTV state enable
config igmp_snooping multicast_vlan IPTV add member_port 1-24
config igmp_snooping multicast_vlan IPTV add source_port 25-28

# VLAN

enable pvid auto_assign
config vlan default delete 1-28
config vlan default add forbidden 1-24,27-28
config vlan default advertisement enable
create vlan VLAN3 tag 3
config vlan VLAN3 add tagged 25-28
config vlan VLAN3 add untagged 1-23 advertisement disable
create vlan ERPS_vlan tag 72
config vlan ERPS_vlan add tagged 25-28 advertisement disable
create vlan VLAN100 tag 100
config vlan VLAN100 add tagged 25-26 advertisement disable
create vlan VLAN256 tag 256
config vlan VLAN256 add tagged 25-28 advertisement disable
create vlan VLAN785 tag 785
config vlan VLAN785 add tagged 25-26
config vlan VLAN785 add untagged 24 advertisement disable
disable qinq
disable gvrp
config gvrp nni_bpdu_addr dot1d
disable vlan_trunk
config port_vlan 1-23 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 3
config port_vlan 24 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 785
config port_vlan 25-28 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 1

# MULTICAST_FILTER

create mcast_filter_profile profile_id 1 profile_name IPTV-Multicast-GroupChanell
config mcast_filter_profile profile_id 1 add 226.100.10.1-226.100.10.81
config mcast_filter_profile profile_id 1 add 233.12.144.1-233.12.144.90
config mcast_filter_profile profile_id 1 add 239.1.29.1-239.2.29.10
config limited_multicast_addr ports 1 add profile_id 1
config max_mcast_group ports 1 max_group 2
config limited_multicast_addr ports 2 add profile_id 1
config max_mcast_group ports 2 max_group 2
config limited_multicast_addr ports 3 add profile_id 1
config max_mcast_group ports 3 max_group 2
config limited_multicast_addr ports 4 add profile_id 1
config max_mcast_group ports 4 max_group 2
config limited_multicast_addr ports 5 add profile_id 1
config max_mcast_group ports 5 max_group 2
config limited_multicast_addr ports 6 add profile_id 1
config max_mcast_group ports 6 max_group 2
config limited_multicast_addr ports 7 add profile_id 1
config max_mcast_group ports 7 max_group 2
config limited_multicast_addr ports 8 add profile_id 1
config max_mcast_group ports 8 max_group 2
config limited_multicast_addr ports 9 add profile_id 1
config max_mcast_group ports 9 max_group 2
config limited_multicast_addr ports 10 add profile_id 1
config max_mcast_group ports 10 max_group 2
config limited_multicast_addr ports 11 add profile_id 1
config max_mcast_group ports 11 max_group 2
config limited_multicast_addr ports 12 add profile_id 1
config max_mcast_group ports 12 max_group 2
config limited_multicast_addr ports 13 add profile_id 1
config max_mcast_group ports 13 max_group 2
config limited_multicast_addr ports 14 add profile_id 1
config max_mcast_group ports 14 max_group 2
config limited_multicast_addr ports 15 add profile_id 1
config max_mcast_group ports 15 max_group 2
config limited_multicast_addr ports 16 add profile_id 1
config max_mcast_group ports 16 max_group 2
config limited_multicast_addr ports 17 add profile_id 1
config max_mcast_group ports 17 max_group 2
config limited_multicast_addr ports 18 add profile_id 1
config max_mcast_group ports 18 max_group 2
config limited_multicast_addr ports 19 add profile_id 1
config max_mcast_group ports 19 max_group 2
config limited_multicast_addr ports 20 add profile_id 1
config max_mcast_group ports 20 max_group 2
config limited_multicast_addr ports 21 add profile_id 1
config max_mcast_group ports 21 max_group 2
config limited_multicast_addr ports 22 add profile_id 1
config max_mcast_group ports 22 max_group 2
config limited_multicast_addr ports 23 add profile_id 1
config max_mcast_group ports 23 max_group 2
config limited_multicast_addr ports 24 add profile_id 1
config max_mcast_group ports 24 max_group 2
config max_mcast_group ports 25 max_group 256
config max_mcast_group ports 26 max_group 256
config max_mcast_group ports 27 max_group 256
config max_mcast_group ports 28 max_group 256

# ERPS

config erps version g.8032v1
create erps ring ring_72
config erps ring ring_72 ring_port west 25
config erps ring ring_72 ring_port east 26
config erps ring ring_72 ring_id 1
config erps ring ring_72 add instance 1
config erps instance 1 raps_vlan 72
config erps instance 1 timer wtr_time 1
config erps instance 1 protected_vlan add vlanid 3
config erps instance 1 protected_vlan add vlanid 5
config erps instance 1 protected_vlan add vlanid 100
config erps instance 1 protected_vlan add vlanid 256
config erps instance 1 protected_vlan add vlanid 785
config erps instance 1 state enable
config erps log enable
enable erps

# MCFILTER

config multicast vlan_filtering_mode vlanid 1 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 3 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 5 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 72 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 785 filter_unregistered_groups

# IGMP_SNOOPING

enable igmp_snooping
config igmp_snooping data_driven_learning max_learned_entry 56
config igmp_snooping vlan_name default fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name default query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name default expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name VLAN3 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN3 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN3 expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name IPTV fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0
config igmp_snooping querier vlan_name IPTV query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name IPTV expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name ERPS_vlan fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name ERPS_vlan query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name ERPS_vlan expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN100 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN100 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN100 expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN256 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN256 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN256 expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN785 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN785 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN785 expiry_time 260 state enable aged_out disable
config cpu_filter l3_control_pkt 1-24 dvmrp pim igmp_query ospf rip vrrp state enable
config cpu_filter l3_control_pkt 25-28 all state disable

enable jumbo_frame
config autocable_diag ports 1-28 state disable
config ports 1-28 linkchange_logs enable
config ports 1 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 2,24 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto
config ports 3,7-8 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state disable mdix auto description VACANT
config ports 4 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 5 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state disable mdix auto description VACANT
config ports 6,9-23 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state disable mdix auto
config ports 25-26 medium_type copper speed auto capability_advertised 10_half 10_full 100_half 100_full 1000_full flow_control disable learning enable state enable mdix auto
config ports 25-26 medium_type fiber speed auto capability_advertised 1000_full flow_control disable learning enable state enable
config ports 27-28 speed auto capability_advertised 1000_full flow_control disable learning enable state enable

# IGMP_MULTICAST_VLAN

disable igmp_snooping multicast_vlan
config igmp_snooping multicast_vlan forward_unmatched disable

# VLAN

enable pvid auto_assign
config vlan default delete 1-28
config vlan default add forbidden 1-25,27-28
config vlan default advertisement enable
create vlan VLAN3 tag 3
config vlan VLAN3 add tagged 25-28
config vlan VLAN3 add untagged 1-4,6-23 advertisement disable
create vlan ERPS_vlan tag 72
config vlan ERPS_vlan add tagged 25-28 advertisement disable
create vlan VLAN100 tag 100
config vlan VLAN100 add tagged 25-26
config vlan VLAN100 add untagged 5 advertisement disable
create vlan VLAN256 tag 256
config vlan VLAN256 add tagged 25-28 advertisement disable
create vlan VLAN785 tag 785
config vlan VLAN785 add tagged 25-28
config vlan VLAN785 add untagged 24 advertisement disable
disable qinq
disable gvrp
config gvrp nni_bpdu_addr dot1d
disable vlan_trunk
config port_vlan 1-4,6-23 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 3
config port_vlan 5 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 100
config port_vlan 24 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 785
config port_vlan 25-28 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 1

# MULTICAST_FILTER

create mcast_filter_profile profile_id 1 profile_name IPTV-Multicast-GroupChanell
config mcast_filter_profile profile_id 1 add 226.100.10.1-226.100.10.81
config mcast_filter_profile profile_id 1 add 233.12.144.1-233.12.144.90
config mcast_filter_profile profile_id 1 add 239.1.29.1-239.2.29.10
config limited_multicast_addr ports 1 add profile_id 1
config max_mcast_group ports 1 max_group 2
config limited_multicast_addr ports 2 add profile_id 1
config max_mcast_group ports 2 max_group 2
config limited_multicast_addr ports 3 add profile_id 1
config max_mcast_group ports 3 max_group 2
config limited_multicast_addr ports 4 add profile_id 1
config max_mcast_group ports 4 max_group 2
config limited_multicast_addr ports 5 add profile_id 1
config max_mcast_group ports 5 max_group 2
config limited_multicast_addr ports 6 add profile_id 1
config max_mcast_group ports 6 max_group 2
config limited_multicast_addr ports 7 add profile_id 1
config max_mcast_group ports 7 max_group 2
config limited_multicast_addr ports 8 add profile_id 1
config max_mcast_group ports 8 max_group 2
config limited_multicast_addr ports 9 add profile_id 1
config max_mcast_group ports 9 max_group 2
config limited_multicast_addr ports 10 add profile_id 1
config max_mcast_group ports 10 max_group 2
config limited_multicast_addr ports 11 add profile_id 1
config max_mcast_group ports 11 max_group 2
config limited_multicast_addr ports 12 add profile_id 1
config max_mcast_group ports 12 max_group 2
config limited_multicast_addr ports 13 add profile_id 1
config max_mcast_group ports 13 max_group 2
config limited_multicast_addr ports 14 add profile_id 1
config max_mcast_group ports 14 max_group 2
config limited_multicast_addr ports 15 add profile_id 1
config max_mcast_group ports 15 max_group 2
config limited_multicast_addr ports 16 add profile_id 1
config max_mcast_group ports 16 max_group 2
config limited_multicast_addr ports 17 add profile_id 1
config max_mcast_group ports 17 max_group 2
config limited_multicast_addr ports 18 add profile_id 1
config max_mcast_group ports 18 max_group 2
config limited_multicast_addr ports 19 add profile_id 1
config max_mcast_group ports 19 max_group 2
config limited_multicast_addr ports 20 add profile_id 1
config max_mcast_group ports 20 max_group 2
config limited_multicast_addr ports 21 add profile_id 1
config max_mcast_group ports 21 max_group 2
config limited_multicast_addr ports 22 add profile_id 1
config max_mcast_group ports 22 max_group 2
config limited_multicast_addr ports 23 add profile_id 1
config max_mcast_group ports 23 max_group 2
config limited_multicast_addr ports 24 add profile_id 1
config max_mcast_group ports 24 max_group 2
config max_mcast_group ports 25 max_group 256
config max_mcast_group ports 26 max_group 256
config max_mcast_group ports 27 max_group 256
config max_mcast_group ports 28 max_group 256

# ERPS

config erps version g.8032v1
create erps ring ring_72
config erps ring ring_72 ring_port west 25
config erps ring ring_72 ring_port east 26
config erps ring ring_72 ring_id 1
config erps ring ring_72 add instance 1
config erps instance 1 raps_vlan 72
config erps instance 1 rpl_port west
config erps instance 1 rpl_role owner
config erps instance 1 timer wtr_time 1
config erps instance 1 protected_vlan add vlanid 3
config erps instance 1 protected_vlan add vlanid 5
config erps instance 1 protected_vlan add vlanid 100
config erps instance 1 protected_vlan add vlanid 256
config erps instance 1 protected_vlan add vlanid 785
config erps instance 1 state enable
config erps log enable
enable erps

# MCFILTER

config multicast vlan_filtering_mode vlanid 1 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 3 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 72 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 785 filter_unregistered_groups

# IGMP_SNOOPING

disable igmp_snooping
config igmp_snooping data_driven_learning max_learned_entry 56
config igmp_snooping vlan_name default fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name default query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name default expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name VLAN3 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN3 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN3 expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name ERPS_vlan fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name ERPS_vlan query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name ERPS_vlan expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN100 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN100 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN100 expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN256 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN256 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN256 expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN785 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN785 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN785 expiry_time 260 state enable aged_out disable
config cpu_filter l3_control_pkt 1-24 dvmrp pim igmp_query ospf rip vrrp state enable
config cpu_filter l3_control_pkt 25-28 all state disable

# PORT

enable jumbo_frame
config autocable_diag ports 1-28 state disable
config ports 1-28 linkchange_logs enable
config ports 1 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 2,7,11-12,24 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto
config ports 3 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 4 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state disable mdix auto description
config ports 5 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 6 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 8 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 9 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 10 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state disable mdix auto description
config ports 13-23 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state disable mdix auto
config ports 25-26 medium_type copper speed auto capability_advertised 10_half 10_full 100_half 100_full 1000_full flow_control disable learning enable state enable mdix auto
config ports 25-26 medium_type fiber speed auto capability_advertised 1000_full flow_control disable learning enable state enable
config ports 27-28 speed auto capability_advertised 1000_full flow_control disable learning enable state enable

# IGMP_MULTICAST_VLAN

enable igmp_snooping multicast_vlan
config igmp_snooping multicast_vlan forward_unmatched disable
create igmp_snooping multicast_vlan IPTV 5
config igmp_snooping multicast_vlan IPTV state enable
config igmp_snooping multicast_vlan IPTV add member_port 1-24
config igmp_snooping multicast_vlan IPTV add source_port 25-28

# VLAN

enable pvid auto_assign
config vlan default delete 1-28
config vlan default add forbidden 1-24,27-28
config vlan default advertisement enable
create vlan VLAN3 tag 3
config vlan VLAN3 add tagged 25-28
config vlan VLAN3 add untagged 1-23 advertisement disable
create vlan ERPS_vlan tag 72
config vlan ERPS_vlan add tagged 25-28 advertisement disable
create vlan VLAN100 tag 100
config vlan VLAN100 add tagged 25-28 advertisement disable
create vlan VLAN256 tag 256
config vlan VLAN256 add tagged 25-28 advertisement disable
create vlan VLAN785 tag 785
config vlan VLAN785 add tagged 25-28
config vlan VLAN785 add untagged 24 advertisement disable
disable qinq
disable gvrp
config gvrp nni_bpdu_addr dot1d
disable vlan_trunk
config port_vlan 1-23 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 3
config port_vlan 24 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 785
config port_vlan 25-28 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid

# MULTICAST_FILTER

create mcast_filter_profile profile_id 1 profile_name IPTV-Multicast-GroupChanell
config mcast_filter_profile profile_id 1 add 226.100.10.1-226.100.10.81
config mcast_filter_profile profile_id 1 add 233.12.144.1-233.12.144.90
config mcast_filter_profile profile_id 1 add 239.1.29.1-239.2.29.10
config limited_multicast_addr ports 1 add profile_id 1
config max_mcast_group ports 1 max_group 2
config limited_multicast_addr ports 2 add profile_id 1
config max_mcast_group ports 2 max_group 2
config limited_multicast_addr ports 3 add profile_id 1
config max_mcast_group ports 3 max_group 2
config limited_multicast_addr ports 4 add profile_id 1
config max_mcast_group ports 4 max_group 2
config limited_multicast_addr ports 5 add profile_id 1
config max_mcast_group ports 5 max_group 2
config limited_multicast_addr ports 6 add profile_id 1
config max_mcast_group ports 6 max_group 2
config limited_multicast_addr ports 7 add profile_id 1
config max_mcast_group ports 7 max_group 2
config limited_multicast_addr ports 8 add profile_id 1
config max_mcast_group ports 8 max_group 2
config limited_multicast_addr ports 9 add profile_id 1
config max_mcast_group ports 9 max_group 2
config limited_multicast_addr ports 10 add profile_id 1
config max_mcast_group ports 10 max_group 2
config limited_multicast_addr ports 11 add profile_id 1
config max_mcast_group ports 11 max_group 2
config limited_multicast_addr ports 12 add profile_id 1
config max_mcast_group ports 12 max_group 2
config limited_multicast_addr ports 13 add profile_id 1
config max_mcast_group ports 13 max_group 2
config limited_multicast_addr ports 14 add profile_id 1
config max_mcast_group ports 14 max_group 2
config limited_multicast_addr ports 15 add profile_id 1
config max_mcast_group ports 15 max_group 2
config limited_multicast_addr ports 16 add profile_id 1
config max_mcast_group ports 16 max_group 2
config limited_multicast_addr ports 17 add profile_id 1
config max_mcast_group ports 17 max_group 2
config limited_multicast_addr ports 18 add profile_id 1
config max_mcast_group ports 18 max_group 2
config limited_multicast_addr ports 19 add profile_id 1
config max_mcast_group ports 19 max_group 2
config limited_multicast_addr ports 20 add profile_id 1
config max_mcast_group ports 20 max_group 2
config limited_multicast_addr ports 21 add profile_id 1
config max_mcast_group ports 21 max_group 2
config limited_multicast_addr ports 22 add profile_id 1
config max_mcast_group ports 22 max_group 2
config limited_multicast_addr ports 23 add profile_id 1
config max_mcast_group ports 23 max_group 2
config limited_multicast_addr ports 24 add profile_id 1
config max_mcast_group ports 24 max_group 2
config max_mcast_group ports 25 max_group 256
config max_mcast_group ports 26 max_group 256
config max_mcast_group ports 27 max_group 256
config max_mcast_group ports 28 max_group 256

# ERPS

config erps version g.8032v1
create erps ring ring_72
config erps ring ring_72 ring_port west 26
config erps ring ring_72 ring_port east 27
config erps ring ring_72 ring_id 1
config erps ring ring_72 add instance 1
config erps instance 1 raps_vlan 72
config erps instance 1 timer wtr_time 1
config erps instance 1 protected_vlan add vlanid 3
config erps instance 1 protected_vlan add vlanid 5
config erps instance 1 protected_vlan add vlanid 100
config erps instance 1 protected_vlan add vlanid 256
config erps instance 1 protected_vlan add vlanid 785
config erps instance 1 state enable
config erps log enable
enable erps

# MCFILTER

config multicast vlan_filtering_mode vlanid 1 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 3 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 5 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 100 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 256 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 785 filter_unregistered_groups

# IGMP_SNOOPING

enable igmp_snooping
config igmp_snooping data_driven_learning max_learned_entry 56
config igmp_snooping vlan_name default fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name default query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name default expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name VLAN3 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN3 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN3 expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name IPTV fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0
config igmp_snooping querier vlan_name IPTV query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disableversion 3
config igmp_snooping data_driven_learning vlan_name IPTV expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name ERPS_vlan fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name ERPS_vlan query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name ERPS_vlan expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN100 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN100 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN100 expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN256 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN256 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN256 expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN785 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN785 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN785 expiry_time 260 state enable aged_out disable
config cpu_filter l3_control_pkt 1-24 dvmrp pim igmp_query ospf rip vrrp state enable
config cpu_filter l3_control_pkt 25-28 all state disable

# PORT

enable jumbo_frame
config autocable_diag ports 1-28 state disable
config ports 1-28 linkchange_logs enable
config ports 1,3-6,8,13-23 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state disable mdix auto
config ports 2 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 7 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 9 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 10 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 11 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto description
config ports 12,24 speed auto capability_advertised 10_half 10_full 100_half 100_full flow_control disable learning enable state enable mdix auto
config ports 25-26 medium_type copper speed auto capability_advertised 10_half 10_full 100_half 100_full 1000_full flow_control disable learning enable state enable mdix auto
config ports 25-26 medium_type fiber speed auto capability_advertised 1000_full flow_control disable learning enable state enable
config ports 27-28 speed auto capability_advertised 1000_full flow_control disable learning enable state enable

# VLAN

enable pvid auto_assign
config vlan default delete 1-28
config vlan default add forbidden 1-24,27-28
config vlan default advertisement enable
create vlan VLAN3 tag 3
config vlan VLAN3 add tagged 25-28
config vlan VLAN3 add untagged 1-23 advertisement disable
create vlan ERPS_vlan tag 72
config vlan ERPS_vlan add tagged 25-28 advertisement disable
create vlan VLAN100 tag 100
config vlan VLAN100 add tagged 25-26 advertisement disable
create vlan VLAN256 tag 256
config vlan VLAN256 add tagged 25-28 advertisement disable
create vlan VLAN785 tag 785
config vlan VLAN785 add tagged 25-28
config vlan VLAN785 add untagged 24 advertisement disable
disable qinq
disable gvrp
config gvrp nni_bpdu_addr dot1d
disable vlan_trunk
config port_vlan 1-23 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 3
config port_vlan 24 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 785
config port_vlan 25-28 gvrp_state disable ingress_checking enable acceptable_frame admit_all pvid 1

# MULTICAST_FILTER

create mcast_filter_profile profile_id 1 profile_name IPTV-Multicast-GroupChanell
config mcast_filter_profile profile_id 1 add 226.100.10.1-226.100.10.81
config mcast_filter_profile profile_id 1 add 233.12.144.1-233.12.144.90
config mcast_filter_profile profile_id 1 add 239.1.29.1-239.2.29.10
config limited_multicast_addr ports 1 add profile_id 1
config max_mcast_group ports 1 max_group 2
config limited_multicast_addr ports 2 add profile_id 1
config max_mcast_group ports 2 max_group 2
config limited_multicast_addr ports 3 add profile_id 1
config max_mcast_group ports 3 max_group 2
config limited_multicast_addr ports 4 add profile_id 1
config max_mcast_group ports 4 max_group 2
config limited_multicast_addr ports 5 add profile_id 1
config max_mcast_group ports 5 max_group 2
config limited_multicast_addr ports 6 add profile_id 1
config max_mcast_group ports 6 max_group 2
config limited_multicast_addr ports 7 add profile_id 1
config max_mcast_group ports 7 max_group 2
config limited_multicast_addr ports 8 add profile_id 1
config max_mcast_group ports 8 max_group 2
config limited_multicast_addr ports 9 add profile_id 1
config max_mcast_group ports 9 max_group 2
config limited_multicast_addr ports 10 add profile_id 1
config max_mcast_group ports 10 max_group 2
config limited_multicast_addr ports 11 add profile_id 1
config max_mcast_group ports 11 max_group 2
config limited_multicast_addr ports 12 add profile_id 1
config max_mcast_group ports 12 max_group 2
config limited_multicast_addr ports 13 add profile_id 1
config max_mcast_group ports 13 max_group 2
config limited_multicast_addr ports 14 add profile_id 1
config max_mcast_group ports 14 max_group 2
config limited_multicast_addr ports 15 add profile_id 1
config max_mcast_group ports 15 max_group 2
config limited_multicast_addr ports 16 add profile_id 1
config max_mcast_group ports 16 max_group 2
config limited_multicast_addr ports 17 add profile_id 1
config max_mcast_group ports 17 max_group 2
config limited_multicast_addr ports 18 add profile_id 1
config max_mcast_group ports 18 max_group 2
config limited_multicast_addr ports 19 add profile_id 1
config max_mcast_group ports 19 max_group 2
config limited_multicast_addr ports 20 add profile_id 1
config max_mcast_group ports 20 max_group 2
config limited_multicast_addr ports 21 add profile_id 1
config max_mcast_group ports 21 max_group 2
config limited_multicast_addr ports 22 add profile_id 1
config max_mcast_group ports 22 max_group 2
config limited_multicast_addr ports 23 add profile_id 1
config max_mcast_group ports 23 max_group 2
config limited_multicast_addr ports 24 add profile_id 1
config max_mcast_group ports 24 max_group 2
config max_mcast_group ports 25 max_group 256
config max_mcast_group ports 26 max_group 256
config max_mcast_group ports 27 max_group 256
config max_mcast_group ports 28 max_group 256

# ERPS

config erps version g.8032v1
create erps ring ring_72
config erps ring ring_72 ring_port west 25
config erps ring ring_72 ring_port east 26
config erps ring ring_72 ring_id 1
config erps ring ring_72 add instance 1
config erps instance 1 raps_vlan 72
config erps instance 1 timer wtr_time 1
config erps instance 1 protected_vlan add vlanid 3
config erps instance 1 protected_vlan add vlanid 5
config erps instance 1 protected_vlan add vlanid 100
config erps instance 1 protected_vlan add vlanid 256
config erps instance 1 protected_vlan add vlanid 785
config erps instance 1 state enable
config erps log enable
enable erps

# MCFILTER

config multicast vlan_filtering_mode vlanid 3 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 100 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 256 filter_unregistered_groups
config multicast vlan_filtering_mode vlanid 785 filter_unregistered_groups

# IGMP_SNOOPING

disable igmp_snooping
config igmp_snooping data_driven_learning max_learned_entry 56
config igmp_snooping vlan_name default fast_leave enable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name default query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name default expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name VLAN3 fast_leave enable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN3 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN3 expiry_time 260 state disable aged_out disable
config igmp_snooping vlan_name ERPS_vlan fast_leave enable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name ERPS_vlan query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name ERPS_vlan expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN100 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN100 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN100 expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN256 fast_leave disable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN256 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN256 expiry_time 260 state enable aged_out disable
config igmp_snooping vlan_name VLAN785 fast_leave enable report_suppression enable proxy_reporting state disable source_ip 0.0.0.0 state disable
config igmp_snooping querier vlan_name VLAN785 query_interval 125 max_response_time 10 robustness_variable 2 last_member_query_interval 1 state disable version 3
config igmp_snooping data_driven_learning vlan_name VLAN785 expiry_time 260 state enable aged_out disable
config cpu_filter l3_control_pkt 1-24 dvmrp pim igmp_query ospf rip vrrp state enable
config cpu_filter l3_control_pkt 25-28 all state disable
